Production capacity
|
18-19 strings/min.
|
|
Hot melt application system
|
Nordson (USA) or Robatech (Switzerland)
|
|
Capacity of glue tank
|
30kg+18kg
|
|
Gluing method
|
Spot spray, continuous spray and general economic mode
|
|
Possibility of assembling sofa core
|
Available
|
|
Air consumption
|
0.3m³/min.
|
|
Weight
|
Approx.10000Kg
|
| Consumption Material Data |
| Non-woven fabric | |
| Fabric density | 65~80g/㎡ |
| Fabric width | 450-2200mm |
| Inner dia.of fabric roll | Min.60mm |
| Outer dia.of fabric roll | Min.600mm |
| Foam strip |
|
| Foam strip thickness |
60-100mm |
| Foam strip height |
80-250mm |
| Foam strip length |
1000-2200mm |
| PK material roll |
|
| PK material roll width |
Max.2200mm |
| PK material roll inner dia. |
Min.60mm |
| PK material roll outer dia. |
Max.600mm |
