| Production capacity | 160 springs/min. |
| Coiling head | Single wire servo coiling head |
| Working principle | Servo control |
| Spring shape | Standard versions：barrel and cylindrical |
| Air consumption | 0.3m³ /min. |
| Air pressure | 0.6-0.7 mpa |
| Power consumption in total | 40KW |
| Working temperature | +5℃~+35℃ |
| Weight | Approx.4000Kg |
| Voltage | 3AC 380V |
