Machine model
|
ZLT-YS66
|
ZLT-YS96
|
ZLT-YS128
|
|
Dimension（L*W*H）
|
3820*1250*1780mm
|
4940*1250*1780mm
|
5800*1250*1780mm
|
|
Gross weight
|
2800kg
|
3500kg
|
4000kg
|
|
Quilting width
|
1700mm
|
2450mm
|
3300mm
|
|
Space between needle rows
|
76.2mm
|
76.2+76.2mm
|
76.2+76.2mm
|
|
Space between needle
|
25.4mm
|
25.4mm
|
25.4mm
|
|
Max. horizonal movement
|
203.2mm
|
304.8mm
|
304.8mm
|
|
Quilting thickness
|
≤30mm
|
≤30mm
|
≤30mm
|
|
Stitch length
|
2-7mm
|
2-7mm
|
2-7mm
|
|
Production speed
|
60-130m/h
|
60-120m/h
|
60-110m/h
|
1. Outstanding computerized system and advanced mechanical technology ensure low noise.
2. The needle bar design of needles connect bar frame without tube, avoid to dirty fabrics, the structure is not easy to damage, low maintenance costing.
3. The main axis are adopted frequency conversion control, saddle and roller are adopted high precision servo drive and motor.
4. Pin and platen transmission swing arm using special aluminum finishing and the surface by a special treatment, more stable in operation to achieve smaller vibration effect.
5. Update machine structure and design increasing machine base weight make machine running more stable, long life lasting.
6. Computer control speed, needle speed can reach 1100 rpm, stitch length 2-7mm.
7. 360° quilting and unlimited independent quilted pattern step.
