Production capacity |
280 springs/min. |
|
Coiling head |
Single wire servo coiling head/ Double wire servo coiling head |
|
Working principle |
Servo control |
|
Spring shape |
Standard versions：barrel and cylindrical |
|
Air consumption |
0.4m³/min. |
|
Air pressure |
0.6-0.7 mpa |
|
Power consumption in total |
55KW |
|
Voltage |
3AC 380V |
|
Input current |
90A |
|
Cable section |
3*35mm² + 2*16mm² |
|
Working temperature |
+5℃~+35℃ |
